Vertical-circulation Parking System
Main Technical Parameters :
| No. | Name | SEDAN | SUV | |
|---|---|---|---|---|
| 1 | Vehicle size | Length (mm) | 5000 | 5300 |
| Width (mm) | 2000 | 2100 | ||
| Height (mm) | 1550 | 2000 | ||
| 2 | Vehicle weight (Kg) | 2000 | 2500 | |
| 3 | Parking capacity | 8 | 8 | |
| 4 | Drive Mode | Gear Motor + Chain | Gear Motor + Chain | |
| 5 | Operation control mode | Frequency inverter | Frequency inverter | |
| 6 | Power Supply | 3 Phase AC 380V 50Hz | 3 Phase AC 380V 50Hz | |
| 7 | Motor Power | 7.5 kW | 9.2 kW | |
Features :
- The motor power is designed according to the full offset load, so as to ensure the normal operation of the equipment under extreme offset load conditions;
- Auto balance system for vehicle storage, average offset load of equipment < 1.ST, lighter load, lower motor operating power, longer service life, energy saving 6‹ consumption reduction;
- Small floor area, only 2-3 common parking Spaces;
- Low noise ( 50dB), quieter operation;
- Modular composite units, easy installation & operation;
- Unattended 6‹ non-inductive payment system reduces labor costs & provides all-round services for smart cities. (optional);
- Intelligent security door, intelligent door interlocking system, double-door linkage, intelligent lifting, automatic anti-pinch, low noise & high speed (optional).
